| Technical Specifications | ViewSonic VSD243-BKA-US0 - 24" Interactive Display Panel |
|---|---|
| Screen Size | 24 inches (23.6" viewable) |
| Display Type | IPS LCD (LED backlight) |
| Resolution | 1920 × 1080 (Full HD) |
| Aspect Ratio | 16:9 |
| Touch Technology | 10-point capacitive multi-touch |
| Response Time | 16 ms (GTG) |
| Viewing Angle | 178° horizontal, 178° vertical |
| Brightness | 250 cd/m² |
| Contrast Ratio | 3000:1 (static) |
| Operating System | Android 8.1 (Oreo) |
| Processor | Rockchip RK3288W Quad-core Cortex-A17 1.8GHz |
| Memory / Storage | 2GB DDR3 RAM / 16GB eMMC storage |
| Wireless Connectivity | Wi-Fi 802.11 a/b/g/n/ac, Bluetooth 4.0 |
| Input / Output Ports |
|
| Audio | 2 × 2.5W stereo speakers |
| Camera | 5 MP front-facing webcam with echo-cancelling microphone |
| Dimensions (W × H × D) | 572.9 × 351.8 × 47.0 mm (22.6 × 13.9 × 1.9 in.) |
| Weight | 5.6 kg (12.4 lbs) |
| Mounting Options | VESA 100 × 100 mm (M4 × 4 mm) |
| Power Consumption | 16W (typical), 40W (max), < 2W standby, < 0.5W off |
| Warranty | 3-year limited warranty (Parts, Labor, Backlight) |
The ViewSonic VSD243-BKA-US0 Health Flex Kiosk Bundle is a 24-inch interactive display panel designed for modern public spaces and health-conscious environments. This versatile bundle combines a 24” Full HD touch display, an integrated media player, and an optional automatic hand sanitizer dispenser holder for enhanced hygiene and engagement. Ideal for retail, corporate, and healthcare applications, it delivers powerful performance and intuitive operation.
Powered by a Rockchip RK3288W Quad-Core Cortex-A17 1.8GHz processor and Android 8.1 (Oreo) operating system, the VSD243 ensures smooth performance and reliable functionality. Its 10-point capacitive multi-touch screen offers precise and responsive interaction, while the Full HD 1080p resolution and 178°/178° wide viewing angles provide vivid, consistent visuals from any position. The anti-glare panel with 250 cd/m² brightness and a 3000:1 contrast ratio enhances visibility in various lighting conditions.
A built-in 5MP webcam with an echo-cancelling microphone enables clear communication and content capture, while dual 2.5W stereo speakers deliver crisp, immersive audio. The optional automatic hand sanitizer dispenser promotes a safe and convenient user experience, making this display perfect for digital signage, check-in stations, and self-service kiosks. Paired with optional content management software, users can easily control and schedule dynamic visual content.
Frequently Asked Questions
Q: What is the ViewSonic VSD243-BKA-US0 - 24" Interactive Display Panel?A: The ViewSonic VSD243-BKA-US0 is a 24-inch interactive display panel that offers a range of features for various applications. It features a Full HD display with multi-touch capabilities, built-in speakers, and a variety of connectivity options.
Q: What are the benefits of using an interactive display panel like the ViewSonic VSD243-BKA-US0?A: There are several benefits to using an interactive display panel like the ViewSonic VSD243-BKA-US0:
- Enhanced engagement: The interactive nature of the display allows users to interact with content in a more engaging way, making it ideal for educational purposes, presentations, and collaborative work.
- Improved collaboration: The multi-touch capabilities of the display enable multiple users to collaborate simultaneously, fostering teamwork and creativity.
- Versatile applications: The ViewSonic VSD243-BKA-US0 can be used in various scenarios such as classrooms, boardrooms, retail settings, and interactive digital signage.
- Convenient connectivity: With its range of connectivity options, including HDMI, USB, and VGA, the display panel can easily connect to different devices, such as laptops, tablets, and media players.
- High-quality visuals and audio: The Full HD display ensures crisp and vibrant visuals, while the built-in speakers provide clear audio for an immersive experience.
A: The ViewSonic VSD243-BKA-US0 offers several key features that make it a versatile and user-friendly interactive display panel:
- 24-inch Full HD display with a resolution of 1920 x 1080 pixels, providing sharp and detailed visuals.
- 10-point multi-touch technology, allowing multiple users to interact simultaneously.
- Built-in speakers for clear and immersive audio.
- Multiple connectivity options, including HDMI, USB, and VGA, ensuring compatibility with various devices.
- Android operating system, enabling access to a wide range of apps and content.
- VESA mount compatibility, allowing for easy installation and flexible positioning.
A: The ViewSonic VSD243-BKA-US0 can be used in various scenarios to enhance productivity, engagement, and communication. Some examples include:
- Education: The interactive display panel can be used in classrooms for interactive lessons, collaborative projects, and engaging educational content.
- Business presentations: The touch capabilities and high-quality visuals make it ideal for delivering impactful presentations, showcasing products, and brainstorming sessions.
- Retail settings: The display panel can be used for interactive product demonstrations, digital signage, and engaging customers in-store.
- Conference rooms: The multi-touch display facilitates interactive discussions, video conferencing, and collaborative work during meetings.
- Home entertainment: The ViewSonic VSD243-BKA-US0 can be used for gaming, streaming content, and enjoying multimedia experiences in the comfort of your home.
A: The ViewSonic VSD243-BKA-US0 is designed to be user-friendly and intuitive. The multi-touch capabilities make it easy to navigate and interact with content, while the Android operating system provides a familiar and user-friendly interface. Additionally, the display panel comes with a user-friendly interface and on-screen controls for easy customization and adjustment of settings.
Video
- VSD243 smart display
- Power adapter and cord
- Quick Start Guide
