Technical Specifications
| Specification | Details |
|---|---|
| Panel Size | 65" |
| Type/ Tech | TFT LCD Module with DLED Backlight |
| Display Area (mm) | 1431 (H) x 807 (V) (64.5” diagonal) |
| Aspect Ratio | 16:9 |
| Resolution | 3840 x 2160 |
| Colors | 1.07B colors (10bit) |
| Brightness | 350 nits (typ.) 300 nits (min.) |
| Contrast Ratio | 1200:1 (typ.) |
| Response Time | 8 ms |
| Viewing Angles | H = 178, V = 178 (typ.) |
| Backlight | DLED |
| Backlight Life | 30,000 Hours Min. |
| Hardness | 7H |
| TOUCH | |
| Type/ Tech | IR Recognition |
| Touch Resolution | 32767 x 32767 |
| Touch Point | 20 points touch, 10 points writing |
| Response Time | <15ms |
| System | Windows 10 / Windows 8 / Windows 7 / Windows XP / Vista / Linux / Mac / Android / Wince / Chrome |
| Life Time | 80,000hrs |
| INPUT | |
| HDMI | x 3 |
| RGB / VGA | x 1 |
| DisplayPort | x 1 |
| Audio | x 1 |
| CVBS (AV) | x 1 |
| RS232 | x 1 |
| PC Slot | x 2 |
| OUTPUT | |
| HDMI | x 1 (for all sources) |
| Audio (Earphone out) | x 1 |
| SPDIF | x 1 |
| LAN | |
| RJ45 | x 1 |
| USB | |
| 2.0 Type A | x 4 (front x 2, for both embedded player and slot-in PC) |
| 3.0 Type A | x 2 (front x 1, for both embedded player and slot-in PC) |
| 2.0 Type B (For touch) | x 2 |
| SPEAKERS | |
| 16W x 2 | |
| BUILT-IN PC | |
| Processor | ARM Cortex A53 Quad Core 1.2G Hz CPU |
| Graphic | ARM Mali-450 Quad Core |
| Memory | 2GB DDR3 |
| Storage | 16GB eMMC |
| Networking | 10/100M auto-identification and DHCP |
| COMPATIBILITY | |
| VGA | Refer to timing table |
| HDMI | 3840x2160 |
| DP | 3840x2160 |
| CVBS | 480i |
| POWER | |
| Voltage | 100-240VAC +/- 10% Wide Range |
| Consumption | 190W(Typ, without Slot-In PC); 285W(Typ, Including Slot-In PC) |
| ERGONOMICS | |
| Wall Mount (VESA® ) | 600 x 400mm; Screw: M8 x 25mm |
| OPERATING CONDITIONS | |
| Temperature (º C) | 32°F to 104°F (0°C to 40°C) |
| Humidity | 10% ~ 90% non-condensing |
| DIMENSIONS (W x H x D) | |
| Physical w/o Stand (mm / inch) | 1521 x 922 x 99 / 59.9 x 36.3 x 3.9 |
| Packaging (mm / inch) | 1697 x 1071 x 220 / 66.81 x 42.17 x 8.66 |
| WEIGHT | |
| Net (kg / lb) | 47kg / 103.62lbs |
| Gross (kg / lb) | 60kg / 132.28lbs |
| REGULATIONS | |
| Standard | FCC, cTUVus, CE, CB, RCM |
| What's in the box? | |
| Contents | VGA cable(5 meters)/Power cable(3 meters) x 4/Remote control/USB cable(5 meters)/Audio cable(5 meters)/AV cable/Touching pen x 3/User manual CD wizard/Quick Start Guide/RS232 adapter/Clamp x 5/Plate/Screw x 3 |
Description
The 65" ViewBoard IFP6550 offers a 20-point multi-touch interactive screen capability, allowing for seamless collaboration and interaction. Multiple users can write or draw on the screen with fingers and styluses using its vBoard Embedded software.
With its ultra HD resolution of 3840 x 2160 4K, users can enjoy stunning visuals and crisp image quality. The floating pen feature allows for annotation on demand, making it easy to highlight and emphasize important points. The built-in ARM Quad-core CPU with 16GB storage ensures smooth performance and ample storage space for files and applications.
With out-of-the-box collaboration capabilities and a Bluetooth 4.0 connection, users can easily connect and share content wirelessly. The LB-WIFI-001 wireless AC adapter supports dual frequency 2.4GHz and 5.0GHz bandwidth, providing up to 433Mbps transmission for fast and reliable connectivity. This display delivers optional slot-in PC capability for more computing-intensive interactive applications. The IFP6550 features a VESA-compatible design and can be placed on a wall mount, or on an optional trolley cart for flexible installation in classrooms and corporate meeting rooms.
In the Box
Video
Frequently Asked Questions
Q: What is the ViewSonic IFP6550 - 65" Interactive Flat Panel?A: The ViewSonic IFP6550 is a 65-inch interactive flat panel that offers a range of features for both business and educational purposes. It provides a high-resolution display with touch screen capabilities, as well as built-in speakers and a variety of connectivity options.
Q: How can I benefit from using the ViewSonic IFP6550?A: The ViewSonic IFP6550 offers several benefits in different scenarios: 1. Education: The interactive flat panel allows teachers to create engaging and interactive lessons, making learning more enjoyable for students. It supports multi-touch functionality, enabling collaborative learning activities. 2. Business presentations: With its large display and high-resolution capabilities, the IFP6550 is ideal for delivering impactful presentations. The touch screen allows presenters to annotate and interact with content in real-time, enhancing audience engagement. 3. Video conferencing: The built-in camera and speakers enable seamless video conferencing experiences. The large screen and high-quality display ensure clear and immersive video calls, making remote collaboration more effective. 4. Collaboration: The IFP6550 facilitates teamwork and collaboration by allowing multiple users to interact with the screen simultaneously. This feature is useful for brainstorming sessions, group projects, and interactive discussions. 5. Digital signage: The interactive flat panel can be used as a digital signage solution to display dynamic and engaging content in various settings, such as retail stores, lobbies, and information centers. Q: What are the key features of the ViewSonic IFP6550?
A: The ViewSonic IFP6550 offers a range of key features, including: * 65-inch display with 4K UHD resolution for sharp and vibrant visuals. * 20-point touch screen with smooth and responsive touch capabilities. * Built-in speakers for clear audio during presentations and video playback. * Multiple connectivity options, including HDMI, VGA, USB, and Ethernet. * Compatibility with various operating systems, such as Windows, Mac, and Android. * Anti-glare and anti-fingerprint coating for improved visibility and ease of use. Q: Can the ViewSonic IFP6550 be used in different environments?
A: Yes, the ViewSonic IFP6550 is versatile and can be used in various environments, such as: * Classrooms: The interactive flat panel enhances classroom engagement and facilitates interactive learning experiences. * Meeting rooms: It provides a professional platform for presentations, collaboration, and video conferencing. * Training centers: The large display and touch capabilities make it suitable for interactive training sessions. * Retail spaces: The IFP6550 can serve as an interactive digital signage solution to attract and engage customers. * Public spaces: It can be used in information centers, museums, and exhibitions to provide interactive and informative displays. Q: How user-friendly is the ViewSonic IFP6550?
A: The ViewSonic IFP6550 is designed to be user-friendly. Its intuitive interface and responsive touch screen make it easy to navigate and interact with content. The flat panel also comes with user-friendly software and tools that enhance usability and productivity.
