Technical Specifications
| Sharp PN-CE701H (70" Class) Specifications | |
|---|---|
| Feature | Details |
| Display | |
| Size (Diagonal) | 70" Class (69 1/2" diagonal) |
| Max. Resolution | 3840 x 2160 pixels (4K Ultra HD) |
| Max. Display Colors (approx.) | 1.07 billion colors |
| Pixel Pitch (H × V) | 0.40075 × 0.40075 mm |
| Max. Brightness (average) | 350 cd/m² |
| Contrast Ratio | 4,000:1 |
| Viewing Angle (H/V) | 176°/176° |
| Active Screen Area (W × H) (approx.) | 60 9/16" × 34 1/16" |
| Response Time | 8 ms (gray to gray, average) |
| Backlight | LED, direct lit |
| Touchscreen | |
| Touch Technology | IR (infrared blocking detection method) |
| PC Connection Port | USB (2.0 compliant) (Type B) × 2 (Front × 1, Rear × 1) |
| Power Supply for Touch Panel | Supplied from main unit |
| Multi Touch | 10 points |
| Protection Glass | Thickness: Approx. 4.0 mm, Shock resistance: 130 cm |
| Touch Pen Function Button | N/A (passive pen) |
| Input/Output Terminals | |
| Front Input Terminals | HDMI (HDCP2.2 compatible, HDR10 supported) × 1, 3.5 mm-diameter mini stereo jack × 1 |
| Rear Input Terminals | PC analog: Mini D-sub 15-pin × 2, HDMI (HDCP2.2 compatible, HDR10 supported) × 2, 3.5 mm-diameter mini stereo jack × 2, AV RCA × 1, Component RCA × 1, Audio RCA × 1, RS-232C × 1 |
| Output Terminals | 3.5 mm-diameter mini stereo jack × 1, SPDIF × 1 |
| System | |
| CPU | Arm® Cortex®-A53 processor (quad core) |
| Memory | 1.5 GB |
| Internal Storage | 8 GB |
| External Interface | |
| Front Interface | USB port (2.0-compliant, main unit & OPS) × 1, USB port (2.0-compliant, OPS) × 2 |
| Rear Interface | LAN port (10BASE-T/100BASE-TX) × 1, USB port (2.0-compliant, main unit) × 3, SD card slot (SD/SDHC) × 1 |
| Wireless LAN | Compliant with IEEE802.11ac/n/a/g/b |
| Expansion Slot | 19 V, 4.74 A (power supplied when expanding the functions with an optional part) |
| Speaker Output | |
| Speaker Output | 10 W + 10 W |
| Mounting | |
| Mounting Points | 4 points, 600 × 400 mm pitch, M6 screw |
| Power Supply | |
| Power Supply | 100 V – 240 V AC, 50/60 Hz |
| Power Consumption | 400 W |
| Environmental Conditions | |
| Operating Temperature | 5˚C to 35˚C |
| Operating Humidity | 20% to 80% RH (no condensation) |
| Dimensions & Weight | |
| Dimensions (W × D × H) (approx.) | 64 1/8" × 3 15/16" × 39" |
| Weight (approx.) | 119 lbs |
| Main Accessories | |
| Included Accessories | AC power cord, remote control unit, remote control unit battery (AAA size) × 2, set-up manual, blank sticker, cable clamp × 3, USB cable, pen tray, SHARP Pen software (CD-ROM), touch pen × 2, wireless adapter |
Description
Introducing the Sharp PN-CE701H - 70" AQUOS BOARD 4K Interactive Screen, a cutting-edge display that takes your interactive experience to the next level. With its 70" class (69-1/2" diagonal) screen size and brilliant Ultra-HD (3840 x 2160) LED direct Lit display, every detail comes to life with stunning clarity and vibrant colors. The 10-Point multi-touch screen allows for seamless and intuitive interaction, making it perfect for presentations, collaboration, and educational purposes.
With a brightness of 350 cd/m2 and a contrast ratio of 4,000:1, the Sharp PN-CE701H delivers exceptional image quality in any lighting condition. It also comes with a 3-year limited warranty, ensuring peace of mind and long-lasting performance. The built-in 10W per channel stereo audio system provides immersive sound, while the built-in SoC controller with Arm® Cortex®-A53 processor (quad core) ensures smooth and responsive operation.
- 70" class (69-1/2" diagonal) screen size
- Brilliant Ultra-HD (3840 x 2160) LED direct Lit display
- 10-Point multi-touch screen
- 350 cd/m2 brightness; 4,000:1 contrast ratio
- 3-year limited warranty
- Built-in 10W per channel stereo audio system
- Built-in SoC controller with Arm® Cortex®-A53 processor (quad core)
- Built-in whiteboard application
- Built-in wireless LAN connectivity for wireless presentations
- IR Touch screen technology
- OPS – compliant expansion slot
In the Box
Video
Frequently Asked Questions
Q: What is the Sharp PN-CE701H - 70" AQUOS BOARD 4K Interactive Screen?A: The Sharp PN-CE701H is a 70-inch 4K interactive screen that offers advanced features for interactive presentations, collaboration, and communication. It provides a high-resolution display, touch functionality, and various connectivity options.
Q: How can users benefit from the Sharp PN-CE701H in a business setting?A: The Sharp PN-CE701H offers numerous benefits for businesses, including: * Enhanced presentations: The 4K resolution and large screen size ensure crisp and clear visuals, making presentations more impactful and engaging. * Interactive collaboration: The touch functionality allows multiple users to interact with the screen simultaneously, making it ideal for brainstorming sessions, team collaborations, and group discussions. * Efficient communication: The built-in microphone and speakers enable video conferencing, making remote meetings more effective and efficient. * Versatile connectivity: With HDMI, VGA, USB, and other connectivity options, users can easily connect various devices and share content seamlessly.
Q: How can the Sharp PN-CE701H benefit educational institutions?A: The Sharp PN-CE701H offers several advantages in educational settings: * Interactive learning: The touch screen enables students to actively participate in lessons, enhancing engagement and knowledge retention. * Collaborative projects: The large size and touch functionality facilitate group work and collaborative projects, fostering teamwork and critical thinking skills. * Multimedia presentations: The 4K resolution and high-quality display ensure vibrant visuals, making educational content more engaging and impactful. * Remote learning: The built-in camera and microphone enable video conferencing, allowing students and teachers to connect and interact in virtual classrooms.
Q: What are the key features of the Sharp PN-CE701H?A: The Sharp PN-CE701H offers several notable features, including: * 70-inch 4K UHD display with a resolution of 3840 x 2160 pixels for stunning visuals. * Capacitive touch screen with multi-touch support, allowing up to 10 simultaneous touch points for smooth and intuitive interactions. * Built-in speakers and microphone for audio playback and video conferencing. * HDMI, VGA, and USB connectivity options for easy integration with various devices. * Durable construction and reliable performance for long-term use in demanding environments.
Q: What are some common applications for the Sharp PN-CE701H?A: The Sharp PN-CE701H can be used in a wide range of scenarios, including: * Business presentations and meetings * Classroom teaching and interactive learning * Training sessions and workshops * Video conferencing and remote collaboration * Digital signage and advertising displays * Gaming and interactive entertainment
Q: How user-friendly is the Sharp PN-CE701H?A: The Sharp PN-CE701H is designed to be user-friendly and intuitive. The touch screen is highly responsive, ensuring smooth interactions, and the connectivity options make it easy to connect and share content from various devices. Additionally, the built-in camera and microphone simplify video conferencing and collaboration.
Product Expert Review
Review of the Sharp PN-CE701H - 70" AQUOS BOARD 4K Interactive Screen
Display Quality:
The Sharp PN-CE701H boasts an impressive display quality that enhances visual presentations in both educational and professional settings. The screen resolution is sharp and detailed, providing clear images that captivate viewers. The brightness level is adequate, ensuring that content is easily visible even in well-lit environments. The color accuracy is excellent, delivering vibrant and accurate colors that are crucial for creative work.
The touch responsiveness of the screen is highly impressive, accurately registering touch inputs without any noticeable delay. The multi-touch capabilities allow for collaborative work, supporting multiple users interacting with the screen simultaneously. The anti-glare properties of the screen are effective, reducing reflections and maintaining visibility in various lighting conditions. The wide viewing angles ensure that content can be viewed clearly from different positions, making it suitable for classrooms or meeting rooms.
Performance and Features:
The Sharp PN-CE701H offers a speedy and responsive interface, providing a seamless user experience. This responsiveness is essential for interactive tasks and ensures smooth interactions. The screen is compatible with a wide range of software, making it versatile for different uses, from educational tools to business applications. The pre-installed software tailored for collaboration adds value to its use in team settings.
In terms of connectivity, the PN-CE701H offers multiple options, including HDMI, USB, Wi-Fi, and Bluetooth, allowing for flexible connections with various devices. The additional features like stylus support enhance precision tasks such as drawing or writing, while the gesture recognition adds an intuitive aspect to navigation and control.
User Experience:
Using the Sharp PN-CE701H in various scenarios has been a delight. The touchscreen is highly intuitive and user-friendly, requiring minimal effort to learn and navigate. The learning curve for new users is minimal, making it accessible to users of all tech-savviness levels.
Applications and Use Cases:
The PN-CE701H excels in different scenarios, particularly in education and business settings. Its interactive features are ideal for engaging students in a classroom or facilitating collaborative work in meetings. Industries such as graphic design and architecture could also benefit from its precise touch and display qualities.
Durability and Reliability:
The build quality of the PN-CE701H suggests long-term durability, and the product comes with a warranty, providing assurance of its reliability. The touchscreen's performance remains consistent over time, showing little sign of wear or degradation, which is a testament to its durability.
Price and Value for Money:
When compared to similar products in the market, the Sharp PN-CE701H offers good value for money. It is competitively priced and provides a range of features and performance that justify its cost.
Pros and Cons:
Pros:
- High-quality display with excellent resolution and color accuracy.
- Responsive touch interface with multi-touch capability.
- Comprehensive connectivity options.
- Intuitive and user-friendly interface.
- Durable and reliable with a solid warranty.
Cons:
- Price might be a consideration for budget-conscious buyers.
- Size may be limiting for some use cases.
Conclusion:
The Sharp PN-CE701H is a robust and versatile interactive touchscreen that excels in both educational and professional environments. Its combination of excellent display quality, responsive performance, and user-friendly interface make it a worthy investment for those seeking an interactive solution that enhances user engagement.
