Technical Specifications
| Category | Specification |
|---|---|
| Display | |
| Active Screen Size | 86" |
| Backlight | LED |
| Display Area (in) | 74.6 x 41.9 in |
| Display Ratio | 16:9 |
| Resolution (pixels) | 3840 x 2160 (4K) |
| Colors | 1.07 billion (8 bit) |
| Brightness | 400 cd/m² |
| Dynamic Contrast Ratio | 5000:1 |
| Static Contrast Ratio | By OC spec |
| Response Time | 8 ms |
| Max Response Time | 10 ms |
| Viewing Angle | 178° |
| Lifetime Hours | 50,000 hours |
| Power | |
| Working Voltage | AC100-240V Max 6.5A |
| Max Power Consumption | ≤550W |
| Eco Power Consumption | <270W |
| Standby Power Consumption | <0.5W |
| ENERGY STAR® Compliant | Yes |
| Touch | |
| Touch Solution | IR |
| Transparency | 88% ±3 |
| Haze | By OC spec |
| Touch Surface Hardness | 7H |
| Touch Points | 40 Point |
| Supported Operating System | Windows, Linux, Mac OS, Chrome |
| Touch Screen Writing Tools | Stylus or Finger |
| Environmental Conditions | |
| Storage Temperature | 14°F - 113°F |
| Working Temperature | 32°F - 104°F |
| Storage Humidity | 0~90% RH (non-condensing) |
| Working Humidity | 20~80% RH (non-condensing) |
| Mounting Options | |
| Mounting Options | Wall-mount or Mobile Stand |
| VESA Mount Pattern | 800x400mm |
| Dimensions & Weight | |
| Outline Dimensions (in) | 77.9 x 46.9 x 4.8 in |
| Packing Dimensions (in) | 87.4 x 50.7 x 9.8 in |
| Net Weight (lbs) | 143.3 lbs |
| Gross Weight (lbs) | 180.8 lbs |
| System | |
| SoC Chipset | Amlogic 311D2 |
| RAM | 4 GB |
| ROM | 32 GB |
| Android Version | Android 11.0 |
| External Memory | Expandable up to 64GB |
| I/O Ports | |
| Front Interface | USB Type-C (PD 65W) x 1, HDMI 2.0 x 1, USB Type-B (Touch) x 1, USB (3.0) Type-A x 1, Mic in x 1 |
| Rear Interface | HDMI IN 2.0 x 2, DisplayPort 1.2 x 1, USB Type-B (Touch) x 3, USB 3.0 Type-C (no PD) x 1, USB 3.0 Type-A x 2, USB 3.0 Type-A to Android x 1, HDMI OUT 2.0 x 1, RS232 x 1, RJ45 (Gigabit) IN x 1, RJ45 (Gigabit) OUT x 1, OPS x 1, SPDIF x 1, Audio Line out x 1 |
| Glass Surface Technology | Anti-Glare + Anti-Fingerprint, + Antimicrobial Tempered Glass |
Description
Introducing the InFocus INF8610 - an impressive 86" 4K JTouch Interactive Touch Screen that will revolutionize your interactive experience. With its massive screen size of 85.60" and native resolution of 4K (3840 x 2160), this touch screen delivers stunning visuals and crystal-clear images. The touch technology used is infrared, ensuring accurate and responsive touch capabilities. With a display lifetime maximum of 50000 hours, you can rely on this touch screen for long-lasting performance. The brightness of 400 nits ensures vibrant and vivid visuals, even in well-lit environments. Powered by Android 11, this touch screen offers a user-friendly and intuitive operating system. Plus, it comes with a 3-year warranty for added peace of mind.
- Massive 86" 4K JTouch Interactive Touch Screen
- Infrared touch technology for accurate and responsive touch capabilities
- Impressive display lifetime maximum of 50000 hours
- Vibrant visuals with a brightness of 400 nits
- Powered by Android 11 for a user-friendly operating system
- Comes with a 3-year warranty for added peace of mind
In the Box
Video
Frequently Asked Questions
Q: What is the InFocus INF8610 - 86" 4K JTouch Interactive Touch Screen?A: The InFocus INF8610 is a high-quality interactive touch screen designed for various applications. It features an 86-inch 4K display with multi-touch capabilities, providing an immersive and interactive experience for users.
Q: How can users benefit from the InFocus INF8610?A: The InFocus INF8610 offers numerous benefits for users across different scenarios: - Enhanced Collaboration: The interactive touch screen allows multiple users to collaborate simultaneously, making it ideal for team projects, brainstorming sessions, and group discussions. - Engaging Presentations: With its large 86-inch 4K display, the INF8610 ensures that presentations and visual content are impactful and immersive, capturing the attention of the audience. - Interactive Learning: In educational settings, the INF8610 promotes interactive learning by enabling students to actively engage with educational content, fostering better understanding and retention. - Efficient Meetings: The INF8610 facilitates efficient and productive meetings with its touch capabilities, enabling participants to annotate, highlight, and interact with documents and presentations in real-time. - Versatile Applications: Whether it's for digital signage, gaming, or video conferencing, the INF8610 offers versatility in its applications, catering to the diverse needs of businesses and institutions.
Q: What are the notable features of the InFocus INF8610?A: The InFocus INF8610 boasts several notable features that make it a top choice for interactive touch screens: - 86-inch 4K Display: The INF8610 delivers stunning visuals with its large 86-inch 4K display, providing exceptional clarity and detail. - Multi-Touch Capabilities: With multi-touch support, the INF8610 allows up to 20 simultaneous touch points, enabling seamless interaction for multiple users. - Built-in Speakers: The INF8610 comes equipped with built-in speakers, ensuring high-quality audio for presentations, videos, and conferences. - Extensive Connectivity Options: It offers a range of connectivity options, including HDMI, VGA, USB, and Ethernet, allowing users to connect various devices and peripherals. - Durable Construction: The INF8610 is built to withstand everyday use, featuring a durable design that ensures longevity and reliability.
Q: What are some common applications for the InFocus INF8610?A: The InFocus INF8610 is suitable for a wide range of applications, including: - Corporate presentations and boardroom meetings - Classroom instruction and interactive learning - Training sessions and workshops - Video conferencing and remote collaboration - Gaming and interactive entertainment - Digital signage and advertising displays
Q: Is the InFocus INF8610 user-friendly?A: Absolutely! The InFocus INF8610 is designed to be user-friendly, providing a seamless and intuitive experience. Its responsive touch screen, along with its user-friendly interface, ensures easy navigation and interaction for users of all levels of technical expertise.
