Technical Specifications
| Category | Specification |
|---|---|
| Screen Size | 86 inches |
| Resolution | 4K UHD (3840 × 2160) |
| Brightness | 450 nits |
| Panel Type | IPS (LED backlight) |
| Touch Technology | Infrared touch |
| Touch Points | 20 points |
| Response Time | 8 ms |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 1200:1 (typical) |
| Color Depth | 10-bit (1.07 billion colors) |
| Operating System | Android 8.0 |
| Processor | Quad-core (A73 × 2 + A53 × 2) |
| Memory / Storage | 3GB RAM / 32GB storage |
| Speakers | 2 × 15W |
| Connectivity | 3 × HDMI, 2 × USB-A, 2 × USB-B, 1 × VGA, 1 × LAN, Audio in/out |
| Power Consumption | 174.6 W (typical), < 0.5 W standby |
| Dimensions (W × H × D) | 1991.6 × 1182.6 × 112.8 mm (78.4 × 46.6 × 4.4 inches) |
| Weight | 74.5 kg (164.2 lbs) |
| Mount Compatibility | VESA 700 × 400 mm |
Description
The BenQ RE8601 is an 86-inch interactive display engineered for large-format teaching and collaboration. It combines premium 4K resolution with wide viewing angles and an anti-glare surface, ensuring that every student can clearly follow lessons from anywhere in the classroom. Its expansive screen real estate supports larger fonts, side-by-side content, and group interaction without visual clutter.
Optimized for classroom health and comfort, the RE8601 integrates TÜV-certified germ-resistant glass, flicker-free operation, and low blue light filtering to protect student well-being during frequent and prolonged use. With 20-point multi-touch capability, the display supports hands-on interaction from multiple users, allowing for group-based learning and inclusive instruction.
Teachers can launch EZWrite 5.0 for whiteboarding, cast student screens wirelessly via InstaShare 2, or retrieve cloud-based content using secure AMS login. The RE8601 also features front-accessible ports and a customizable launcher for quick tool access. With its Android-based interface, the display is fully usable without needing an external PC.
For IT teams, the RE8601 supports centralized device control via BenQ’s DMS platform. Admins can push firmware updates, monitor usage, and distribute apps remotely. Built-in X-Sign Broadcast capabilities also allow for real-time campus-wide announcements, making this panel a powerful tool for both teaching and communication.
A: The 86-inch size is ideal for large classrooms, lecture halls, and collaborative meeting rooms where visibility from the back of the space is essential. It supports larger audiences without compromising readability or engagement.
A: With 20-point infrared touch, multiple students can simultaneously write, draw, or interact with on-screen content. It’s great for solving problems as a group, rotating participants, or hosting real-time quizzes and feedback.
A: Yes. The display’s 450-nit brightness and anti-glare coating ensure content remains crisp and readable, even in rooms with strong overhead lighting or natural daylight.
A: The RE8601 includes germ-resistant glass, low blue light filtering, and flicker-free visuals as part of BenQ’s health-first design. These features support wellness in high-use, high-traffic classroom environments.
A: Students and teachers can mirror their devices using InstaShare 2, which supports Miracast, AirPlay, and BenQ's dedicated casting app. This encourages real-time sharing without cables or adapters.
A: Yes. The Android OS allows access to preloaded apps, whiteboarding, screen sharing, and file management features directly on the display. Cloud accounts and lesson content can be accessed using AMS login.
A: The unit is VESA-compatible (700 × 400 mm) and ships with mounting hardware. It can also be used with mobile trolleys designed for large-format displays to support flexible classroom layouts.
A: IT teams can use BenQ’s Device Management System (DMS) to monitor, configure, and update RE8601 panels remotely. It simplifies administration across schools or districts.
A: Yes. X-Sign Broadcast allows administrators to send real-time alerts or scheduled messages to multiple displays, making the RE8601 part of a larger school communication network.
A: The RE8601 ships with two stylus pens, wall mount, remote control, HDMI and VGA cables, a USB-B cable for touch input, and a power cable—everything needed for setup and operation.
