Technical Specifications
| Model: AG Neovo NSD-5501Q Specifications | |
| Panel Spec | |
| Display Type | TFT-LCD |
| Size | 55" |
| Touch Screen | No |
| Resolution | 3840 x 2160 (4K UHD) |
| Aspect Ratio | 16 : 9 |
| Color Depth | 8 bit |
| Contrast Ratio | 1200 : 1 |
| Backlight | LED |
| Viewing Angle | 178° (H), 178° (V) |
| Interfaces | |
| Ethernet | 1 x RJ-45 Female, 10 / 100 / 1000 BaseT |
| USB | 2 x USB Type A, 1 x USB Type B |
| Power Inputs | |
| Power over Ethernet (PoE) | No |
| Power Consumption | AC 100-240V, 50/60Hz, 2.5A |
| Environmental | |
| Operating Temperature | 0 - 40°C |
| Storage Temperature | -20 - 60°C |
| Humidity | 10 - 90% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 24.5 kg ( 54 lb ) |
| Dimensions (L x W x H) | 1243.2 x 712.8 x 77.5 mm (49 x 28 x 3 in.) |
| Note | N/A |
Description
The AG Neovo NSD-5501Q is a 55" 4K UHD digital signage display that offers exceptional clarity and detail. With a brightness of 350 nits, this display ensures that your content is visible even in bright environments. It features an embedded cloud-based CMS, allowing you to easily manage and update your signage content from anywhere. Additionally, the display comes bundled with LAN-based content management software for added convenience. You can also enjoy 4K multimedia playback via USB and Micro SD, making it easy to showcase high-quality videos and images. The IR/RS232/RJ45 connection allows for easy control and management of the display.
The NSD-5501Q is equipped with an enhanced android-powered digital signage platform, providing versatile content playback and scheduling options. Its embedded image enhancer features advanced technologies such as 3D Comb Filter, 3D Deinterlace, Noise Reduction, and Freeze, ensuring crystal clarity in even the most demanding environments. The display supports a wide range of formats, including full-screen HTML5 browsing for live content and PDF playback for presentations. With IR/RS232 daisy chaining capability, you can easily control multiple displays using a single connection or remote control. The display also features patented Anti-Burn-In Technology to prevent image burn-in and extend the lifespan of the display. Additionally, the PID Command & Ctrl software allows for remote management and easy creation of video wall displays.
In the Box
Frequently Asked Questions
Q: What is the AG Neovo NSD-5501Q - 55" 4K UHD Digital Signage Display with Anti-Glare?A: The AG Neovo NSD-5501Q is a high-quality digital signage display designed for businesses and organizations. It features a 55-inch 4K UHD display with anti-glare technology, making it perfect for displaying content in various lighting conditions.
Q: How can the AG Neovo NSD-5501Q benefit my business?A: The AG Neovo NSD-5501Q offers several benefits for businesses, including: * Stunning visual experience: With its 4K UHD resolution and anti-glare technology, the display delivers crisp and vibrant images, ensuring that your content stands out and grabs attention. * Versatile content display: Whether you want to showcase promotional videos, advertisements, or informational content, the AG Neovo NSD-5501Q provides a versatile platform for displaying your content in a visually appealing manner. * Increased customer engagement: The high-quality display and captivating visuals can help attract and engage customers, leading to increased brand awareness and potential sales. * Easy installation and management: The display is designed for easy installation and management, allowing you to quickly set up and control your digital signage network without any hassle.
Q: What are the key features of the AG Neovo NSD-5501Q?A: The AG Neovo NSD-5501Q offers a range of features that make it a top choice for digital signage, including: * 55-inch 4K UHD display: The large display size and high-resolution ensure that your content is displayed with stunning clarity and detail. * Anti-glare technology: The anti-glare coating reduces reflections and glare, ensuring that your content is easily visible even in bright environments. * Wide viewing angles: The display offers wide viewing angles, allowing your content to be seen clearly from different positions and perspectives. * Multiple connectivity options: The display supports various connectivity options, including HDMI, DisplayPort, and VGA, making it compatible with a wide range of devices. * Built-in media player: The display comes with a built-in media player, eliminating the need for external devices and simplifying content playback.
Q: In what scenarios can the AG Neovo NSD-5501Q be used?A: The AG Neovo NSD-5501Q is suitable for a wide range of scenarios, including: * Retail environments: Display promotional offers, product information, and advertisements to attract customers and increase sales. * Corporate settings: Use the display for internal communication, corporate branding, and showcasing company achievements. * Hospitality industry: Provide information to guests, display menus, promote services, and create a visually appealing ambiance. * Educational institutions: Utilize the display for digital signage in classrooms, common areas, and campus information centers. * Entertainment venues: Enhance the visitor experience by displaying event schedules, ticket information, and engaging visuals.
Q: How user-friendly is the AG Neovo NSD-5501Q?A: The AG Neovo NSD-5501Q is designed with user-friendliness in mind. It features an intuitive interface and easy-to-navigate settings, allowing you to quickly set up and manage your digital signage content. Additionally, the display is compatible with popular content management systems, making it seamless to integrate into your existing workflow.
