Samsung OM46D-K - 46" Outdoor Signage Display with Full HD and 2500 Nits

SamsungSKU: Samsung OM46D-K

Sale price$3,483.75

Talk to our experts: Call at 800 992 5279

Product Overview


Technical Specifications

Model: Samsung OM46D-K Specifications
Panel Spec
Display Type TFT-LCD
Size 46"
Resolution 1920 x 1080 (Full HD)
Brightness 2500 nits
Aspect Ratio 16 : 9
Color Depth 8 bit
Contrast Ratio 5000 : 1
Backlight LED
Viewing Angle 178° (H), 178° (V)
Ethernet 1 x RJ-45 Female, 10 / 100 / 1000 BaseT
USB 1 x USB Type A
Power Inputs
Power Consumption AC 100 - 240 V~ (+/- 10%), 50/60 Hz
Operating Temperature -30°C to 50°C
Storage Temperature -40°C to 60°C
Humidity 10 - 80% RH, Non-Condensing
Physical Properties
Housing Metal
Weight 35.3 kg (77.8 lbs)
Dimensions (L x W x H) 1177.2 x 680.4 x 111.5 mm (46.3 x 26.8 x 4.4 in)
IP Rating IP56


The Samsung OM46D-K is a 46" outdoor signage display that offers ultra-high brightness (2,500 nit) with an auto brightness sensor for visibility in ambient light conditions. It has built-in Wi-Fi and mobile app compatibility for centralized, cable-free content management and a reliable 24/7 operation and durability in any sunlight environment. This kit-type display can fit into customized housings to serve a wide range of configurations.

  • Deliver promotional messaging vividly with excellent visibility
  • Draw more visitors to your retail business by effectively delivering promotional messaging with excellent visibility. OMD Series SMART Signage features 2,500-nit high brightness and 5000:1 contrast ratio for superb visibility in various lighting environments. Even customers who are wearing polarized sunglasses can view messages with outstanding clarity and brightness, without the display-blindness effect typically experienced with LCD displays.
  • Display content with optimal brightness and cost-efficiency
  • Optimize brightness control while reducing display operating expenses and power consumption with an automatic brightness sensor. You can customize the maximum and minimum brightness within a range of 350 nits to 2,500-nit brightness to complement any environment and control expenses while extending the life of the monitor.
  • Rely on strong 24/7 durability in various outdoor environments.
  • Present business messaging 24/7 even when the display is exposed to sunlight directly and indirectly for reliable around-the-clock operation. OMD Series SMART Signage is mechanically designed and has undergone internal testing to endure heat with a panel that can withstand up to 110°C (230°F) temperatures.
  • Experience easy management and clutter-free installation with SSSP
  • Leverage Samsung’s industry-leading 2nd Generation SSSP and a powerful quad-core processor with SoC technology for outstanding performance. 2nd Generation SSSP has an advanced MagicInfo® Premium S all-in-one embedded content management solution that eliminates the need for a separate PC or media player. The result is an uncluttered and simplified digital signage configuration that delivers rich media content, enhanced operational efficiency, and lower TCO.
  • Easily and professionally manage content from a mobile device
  • Manage content conveniently from a mobile device with built-in Wi-Fi and MagicInfo® solution, even when the displays are installed in difficult-to-access locations. MagicInfo enables professional management of multiple displays, and the MagicInfo Mobile application can be used on a tablet or other mobile device to easily deliver content to displays or to update the displays’ templates or content.
  • Deliver engaging content with a very visible, sleek, and exceptional design
  • Impress customers and reduce viewing distractions with a sophisticated design featuring a narrow 9.3 mm bezel and slim depth that offers an elegant appearance. Slim bezels allow OMD Series displays to be used in seamless video walls for stunning window and wall displays. And with slim-depth panels, these stylish displays deliver efficient use of space while reducing separate housing design costs.
  • Choose the ideal display type for any business environment
  • Take advantage of a variety of form factors to suit your display environment. As a standalone kit-type panel, the OMD-K is designed for specialized use in various customized housings to serve a wide range of configuration and environmental needs. OMD-W is an aesthetically pleasing standalone panel that is suitable for in-window store display usage with a back cover that hides its array of connectivity ports and openings. Both OMD-K and OMD-W models are available in various sizes (46”, 55”, and 75”) for configuration flexibility.
  • In the Box

    Frequently Asked Questions

    Q: What is the Samsung OM46D-K - 46" Outdoor Signage Display?

    A: The Samsung OM46D-K is a high-quality outdoor signage display designed for businesses and organizations. It features a 46-inch Full HD display with a brightness of 2500 nits, making it perfect for outdoor environments.

    Q: What are the benefits of using the Samsung OM46D-K?

    A: The Samsung OM46D-K offers several benefits for businesses and organizations, including: * High visibility: The 2500 nits brightness ensures that your content is easily visible even in bright outdoor conditions, making it ideal for advertising and promotion. * Durability: The display is designed to withstand various weather conditions and is resistant to dust, water, and other environmental factors, ensuring long-lasting performance. * Full HD resolution: The Full HD display provides crisp and clear visuals, allowing you to showcase your content with high-quality images and videos. * Versatility: The Samsung OM46D-K can be used in various scenarios, such as retail stores, restaurants, transportation hubs, and outdoor events, to attract customers and deliver impactful messages.

    Q: What are the key features of the Samsung OM46D-K?

    A: The Samsung OM46D-K comes with several key features that enhance its functionality and performance, including: * Full HD resolution: The 46-inch display offers a resolution of 1920 x 1080 pixels, ensuring sharp and detailed visuals. * High brightness: With a brightness of 2500 nits, the display delivers vibrant and clear content even in direct sunlight. * Weatherproof design: The display is IP56 certified, making it resistant to dust, water, and extreme temperatures, enabling reliable outdoor usage. * Built-in media player: The display includes a built-in media player, allowing you to easily play and schedule content without the need for additional devices. * Advanced connectivity: The Samsung OM46D-K offers various connectivity options, including HDMI, DVI, USB, and RS232C, enabling seamless integration with other devices.

    Q: What are some possible applications for the Samsung OM46D-K?

    A: The Samsung OM46D-K can be used in a wide range of applications, including: * Outdoor advertising: Promote your products, services, or events with eye-catching visuals and messages that capture the attention of passersby. * Wayfinding: Provide clear directions and information in outdoor spaces, such as shopping centers, parks, and campuses, helping visitors navigate easily. * Digital menu boards: Display menus, specials, and promotions at restaurants, cafes, and food trucks, enhancing customer experience and boosting sales. * Transportation hubs: Inform passengers about schedules, routes, and important announcements at bus stops, train stations, and airports. * Outdoor events: Create immersive experiences and engage attendees at concerts, festivals, sports events, and trade shows with dynamic content.

    Q: How easy is it to install and maintain the Samsung OM46D-K?

    A: The Samsung OM46D-K is designed for easy installation and maintenance. It comes with a mounting kit and detailed instructions, allowing you to set it up quickly. Additionally, the display features a built-in cooling system and self-diagnosis function, making it easy to monitor and maintain optimal performance.
