Technical Specifications
| Model: LG 49VL5GMW-9P Specifications | |
| Panel Spec | |
| Display Type | TFT-LCD |
| Size | 49" |
| Touch Screen | No |
| Resolution | 1920 x 1080 (Full HD) |
| Aspect Ratio | 16 : 9 |
| Color Depth | 8 bit |
| Contrast Ratio | 1,300 : 1 |
| Backlight | LED |
| Viewing Angle | 178°/178° (H/V) |
| Interfaces | |
| Ethernet | 1 x RJ-45 Female, 10 / 100 / 1000 BaseT |
| USB | 1 x USB Type A |
| Power Inputs | |
| Power over Ethernet (PoE) | No |
| Power Consumption | 120W |
| Environmental | |
| Operating Temperature | 0 - 40°C |
| Storage Temperature | -20 - 60°C |
| Humidity | 10 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Plastic |
| Weight | Approx. 18.5 kg (40.79 lbs) |
| Dimensions (L x W x H) | 1075.4 x 606.4 x 89.6 mm (42.34 x 23.87 x 3.53 in.) |
| Note | The dimensions and weight may vary depending on the configuration. |
Description
The LG 49VL5GMW-9P is a 49" screen size black monitor (3x3 ft), featuring IPS panel technology, 1,920 X 1,080 (FHD) resolution, and a brightness of 500 cd/m². This LG's Bezel: 2.25 mm (T/L), 1.25 mm (B/R) Depth: 89.7 mm and it has product Interface: HDMI/ DP/ DVI-D/ USB/ RS232C/ RJ45/ Audio/ IR and it's Power Supply: AC 100-240V~, 50/60Hz with the Power Consumption Typ./Max. 100W / 120W.
- Seamless Large Screens with Ultra- Narrow Bezel
- Image Gap Reduction
- Higher Viewing Angle
- Wide Viewing Angle
- Easy Color Adjustment
- White Balance Adjustment
- User-Friendly Menu Structure
- Intuitive GUI
The ultra-narrow bezel creates a visually stunning digital wall to effectively deliver dynamic content and immerse the viewers. The large screen it generates is enough to captivate the attention of passersby.
The VL5G-M series includes an image improvement algorithm that can reduce image gaps among tiled displays when playing back videos. Objects located on the bezel boundaries are adjusted for a seamless viewing experience. The "LG Conventional" refers to displays that do not include an image improvement algorithm.
Large screens are usually positioned higher than human-eye level, making uniform picture quality essential for video walls. The viewing angle of the VL5G-M series is high enough to display vivid colors throughout the screen with no distortion. Results based on in-house testing. Actual test results may differ depending on the environment and measuring equipment.
It is well known that LG IPS panel technology enables better control of liquid crystals, which in turn allows the screen to be viewed from virtually any angle. Because of this, the VL5G-M series captures the attention of and captivates more viewers with lifelike colors, regardless of their viewing position.
Depending on the content, the display's color temperature can be easily adjusted in increments of 100K using a remote control.
In conventional video walls, white balance was adjustable only in “full-white” mode, but the VL5G-M series allows you to modify each value of greyscale to achieve more detailed and precise white balance adjustment.
The menu structure has been optimized for commercial use. It simplifies approach flows and groups similar functions together, adopting a more intuitive GUI for ease of use. This way, users can avoid having to do trial-and-error when exploring desired functions and managing displays.
The GUI (Graphic User Interface) is carefully designed with a four-way navigation remote control that lets users easily switch to other settings. Also, it adopts a large font for better visibility, which is necessary when users want to control displays from relatively far distances.
In the Box
Frequently Asked Questions
Q: What is the LG 49VL5GMW-9P - 49" Full HD Slim Bezel Video Wall with Peerless Mount, 3x3ft, 500 Nits?A: The LG 49VL5GMW-9P is a high-quality video wall display that offers a slim bezel design and excellent image quality. It features a 49-inch Full HD display with a brightness of 500 nits and comes with a Peerless mount for easy installation.
Q: What are the benefits of using a video wall display?A: Video wall displays offer several benefits for various scenarios, including: * Immersive visual experience: The LG 49VL5GMW-9P provides a large, high-resolution display that can create an immersive visual experience for viewers, making it ideal for advertising, digital signage, and presentations. * Seamless integration: With its slim bezel design, the LG 49VL5GMW-9P can be easily combined with other displays to create a seamless video wall, allowing for larger and more impactful content. * Increased visibility: The 500 nits brightness of the LG 49VL5GMW-9P ensures that the content is easily visible even in bright environments, making it suitable for retail stores, trade shows, and other well-lit areas. * Easy installation: The included Peerless mount makes it simple to install the video wall display, saving time and effort during setup.
Q: What are the key features of the LG 49VL5GMW-9P?A: The LG 49VL5GMW-9P offers several key features that make it an excellent choice for video wall setups, including: * Full HD resolution: The 49-inch display provides a crisp and detailed Full HD resolution, ensuring that your content looks sharp and vibrant. * Slim bezel design: The slim bezels of the LG 49VL5GMW-9P minimize the gap between multiple displays, creating a seamless and visually appealing video wall. * High brightness: With a brightness of 500 nits, the LG 49VL5GMW-9P delivers bright and vivid images, even in well-lit environments. * Peerless mount: The included Peerless mount makes installation quick and hassle-free, allowing you to set up your video wall with ease. * Wide viewing angles: The LG 49VL5GMW-9P offers wide viewing angles, ensuring that your content is easily visible from different perspectives.
Q: What are some of the applications for the LG 49VL5GMW-9P?A: The LG 49VL5GMW-9P can be used in various scenarios, including: * Retail displays: Create eye-catching and engaging product displays in retail stores to attract customers. * Trade shows and events: Showcase your brand and products with a visually stunning video wall display at trade shows and events. * Control rooms: Monitor and display critical information in control rooms with the LG 49VL5GMW-9P's high-quality visuals. * Digital signage: Deliver dynamic and impactful content in airports, hotels, restaurants, and other public spaces. * Conference rooms: Enhance presentations and collaboration in conference rooms with a large and immersive video wall display.
Q: How easy is it to install and set up the LG 49VL5GMW-9P?A: The LG 49VL5GMW-9P is designed for easy installation and setup. With the included Peerless mount, you can quickly and securely mount the display on the wall. The slim bezel design also simplifies the process of creating a video wall by minimizing the gap between displays. Additionally, the user-friendly interface and intuitive controls make it easy to configure and customize the settings according to your needs.
