Technical Specifications
| Model: LG 32HL512D-B - 31.5'' 8MP 4K Nano IPS Color Diagnostic Monitor with Multi Resolution and Clinical Pathology Modes | |
| Panel Spec | |
| Display Type | Nano IPS |
| Size | 31.5" |
| Touch Screen | No |
| Resolution | 8MP 4K (3840 x 2160) |
| Aspect Ratio | 16 : 9 |
| Color Depth | 10 bit |
| Contrast Ratio | 1000 : 1 |
| Backlight | LED |
| Viewing Angle | 178° (H), 178° (V) |
| Interfaces | |
| HDMI | 2 x HDMI |
| DisplayPort | 1 x DisplayPort |
| USB | 2 x USB 3.0 |
| Power Inputs | |
| Power Consumption | 45W |
| Environmental | |
| Operating Temperature | 0 - 40°C |
| Storage Temperature | -20 - 60°C |
| Humidity | 10 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Plastic |
| Weight | 9.6 kg (21.16 lb) |
| Dimensions (L x W x H) | 72.7 x 42.9 x 5.9 cm (28.63 x 16.89 x 2.32 in.) |
Description
The LG 32HL512D-B is a 31.5" 8MP monitor that is FDA approved for the display of radiological images for review, analysis, and diagnosis. With its lightweight and affordable design, this monitor offers excellent image quality, making it the ideal solution for home and reading room use. The 32HL512D-B is DICOM Part 14 factory calibrated to primary diagnostic guidelines, ensuring accurate and reliable image display. Its internal backlight sensor dynamically measures and adjusts LED backlight power to maintain target DICOM brightness over time.
The 31.5-inch 8MP Nano IPS display of the LG 32HL512D-B allows for accurate image viewing from any angle, thanks to its wide 178° viewing angles. This feature enables clinicians to more accurately read multiple screens without any loss in contrast ratio. The monitor also offers a dual video input mode, allowing for the connection of two video sources for operation with PACS applications. Its auto luminance calibration feature ensures sustained picture quality by dynamically measuring and maintaining calibrated DICOM brightness. Additionally, the monitor can be operated in lower 4MP or 6MP resolutions for multiple work list screens, and then switched back to 8MP resolution for reading images. With its clinical pathology mode, the LG 32HL512D-B delivers realistic color reproduction, making it ideal for displaying microscope images with vividness and minimal color distortion.
In the Box
Frequently Asked Questions
Q: What is the LG 32HL512D-B - 31.5'' 8MP 4K Nano IPS Color Diagnostic Monitor with Multi Resolution and Clinical Pathology Modes?A: The LG 32HL512D-B is a high-resolution diagnostic monitor designed for medical professionals. It features a 31.5-inch 8MP 4K Nano IPS display with multi-resolution and clinical pathology modes, providing accurate and detailed imaging for diagnostic purposes.
Q: What are the benefits of using the LG 32HL512D-B in a medical setting?A: The LG 32HL512D-B offers several benefits for medical professionals: * Precise diagnosis: With its high resolution and accurate color reproduction, the monitor ensures accurate and detailed imaging, aiding in accurate diagnosis. * Efficient workflow: The monitor's multi-resolution and clinical pathology modes allow medical professionals to view images at different resolutions and optimize their workflow. * Enhanced visualization: The Nano IPS technology provides vibrant and true-to-life colors, enhancing the visualization of medical images. * Ergonomic design: The monitor's ergonomic design, including adjustable height and tilt, ensures comfortable viewing for long hours.
Q: What are the key features of the LG 32HL512D-B?A: The LG 32HL512D-B offers several key features that make it an ideal choice for medical professionals: * 31.5-inch 8MP 4K Nano IPS display: The high-resolution display ensures accurate and detailed imaging. * Multi-resolution and clinical pathology modes: Medical professionals can view images at different resolutions and optimize their workflow. * Accurate color reproduction: The monitor's Nano IPS technology provides vibrant and true-to-life colors, crucial for accurate diagnosis. * Ergonomic design: The adjustable height and tilt options allow for comfortable viewing during long hours of use. * Wide connectivity options: The monitor supports various connectivity options, including HDMI, DisplayPort, and USB, for easy integration with other devices.
Q: In what scenarios can the LG 32HL512D-B be beneficial?A: The LG 32HL512D-B can be beneficial in various medical scenarios, such as: * Radiology: The high-resolution display and accurate color reproduction are essential for precise interpretation of radiographic images. * Pathology: The clinical pathology mode allows pathologists to view slides and specimens with enhanced clarity and detail. * Telemedicine: The monitor's accurate imaging and wide connectivity options facilitate remote consultations and telemedicine applications. * Surgical imaging: Surgeons can benefit from the monitor's detailed imaging during procedures and surgical planning.
Q: How user-friendly is the LG 32HL512D-B?A: The LG 32HL512D-B is designed with user-friendliness in mind. It features an intuitive interface and easy-to-use controls, allowing medical professionals to navigate through settings and modes effortlessly. The monitor's ergonomic design also ensures comfortable usage for extended periods.
