Resources
Technical Specifications
| Model: LG 21HQ513D-B - 21.3'' 3MP IPS Diagnostic Monitor (1536x2048) | |
| Panel Spec | |
| Display Type | IPS |
| Size | 21.3" |
| Resolution | 1536 x 2048 |
| Aspect Ratio | 4 : 3 |
| Color Depth | 8 bit |
| Contrast Ratio | 1000 : 1 |
| Backlight | LED |
| Viewing Angle | 178° (H), 178° (V) |
| Interfaces | |
| HDMI | 1 x HDMI |
| VGA | 1 x VGA |
| Power Inputs | |
| Power Consumption | 45W |
| Environmental | |
| Operating Temperature | 0 - 40°C |
| Storage Temperature | -20 - 60°C |
| Humidity | 10 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Plastic |
| Weight | 4.5 kg (9.92 lb) |
| Dimensions (L x W x H) | 50.8 x 42.5 x 23.5 cm (20 x 16.7 x 9.3 in.) |
| Note | For some products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
Description
The LG 21HQ513D-B is a 21.3'' 3MP Diagnostic Monitor with a brightness of 1100cd/m² (Typ.) and it features IPS panel type with a resolution of 1536x2048. This LG diagnostic monitor offers a viewing angle of 178°(Right/Left), 178°(Up/Down), and has multi-resolution mode with dual controller. It is backed by a 5-year warranty.
- Manage Effortless Quality Control (Easy Calibration with Front Sensor)
- Multi-resolution Mode (Compatible with Various Devices)
- Pathology Mode (True-to-Life Color Reproduction)
- Streamlined and Efficient Workflow
- Hassle-free Savings & Stronger Security (Presence Sensor)
- Focus View (Fully Focus on the Region of Interest)
- Down Lighting & Wall Lighting (Ideal Diagnostic Workspace)
- 5 Hot Keys (Intuitive Control)
- Auto Luminance Sensor (Reducing Eye Strain)
- Reducing Clutter on Your Desk and Simplifying Cable Management
- Ergonomic Design (Easy and Comfortable Workspace)
The Integrated Front Sensor allows easy calibration without the need for additional measuring equipment. It improves the quality and consistency of displayed medical images by maintaining accurate values.
Diagnostic monitors often need to be connected to various modalities with differing resolutions. Thanks to 21HQ513D’s Multi-resolution Mode, you can adjust the resolution of the monitor to optimize the connected device.
In Pathology Mode, the 21HQ513D reproduces the same level of detail and color accuracy as seen directly under a microscope, to help healthcare professionals make more accurate diagnoses.
Thanks to the Presence Sensor of 21HQ513D which automatically turns off the display when no motion is detected, you can save energy and be more secure against exposing patient information and other sensitive data.
LG 21HQ513D includes the Focus View Mode, allowing you to review a specific part of the medical image more closely. This allows professionals to focus fully on the region of interest of the image for a more accurate and efficient diagnosis.
Down and Wall Lighting Modes reduce the contrast between the monitor brightness and ambient lighting conditions, allowing you to work comfortably without having to adjust the lighting to view paper documents in the darkroom.
The 21HQ513D's 5 Hot Keys make changing between screen modes easier and more intuitive than operating through an OnScreen menu. The 5 Hot Keys are much faster and easier to operate while working, allowing you to change mode and lighting settings all without disrupting your workflow.
LG 21HQ513D features an Auto Luminance Sensor which automatically adjusts screen brightness according to the ambient lighting conditions. As a result, eye strain is reduced by ensuring screen brightness is always set to the optimal level.
The 21HQ513D with 2 USB 3.0 Upstream Port and DisplayPort support Daisy Chain Setup. So you can establish a productive workstation by connecting two diagnostic Monitors and a PC.
The 21HQ513D is designed to be adjustable for the posture of healthcare professionals' image review. So, It helps review medical images more comfortably reducing chronic pain caused by long hours of work.
In the Box
Frequently Asked Questions
Q: What is the LG 21HQ513D-B - 21.3'' 3MP IPS Diagnostic Monitor (1536x2048)?A: The LG 21HQ513D-B is a high-quality diagnostic monitor designed for medical imaging applications. It features a 21.3-inch 3MP IPS display with a resolution of 1536x2048 pixels, providing accurate and detailed images for diagnostic purposes.
Q: What are the benefits of using the LG 21HQ513D-B in medical imaging?A: The LG 21HQ513D-B offers several benefits for medical imaging professionals: * High image quality: With its 3MP resolution and IPS technology, the monitor delivers sharp and precise images, allowing for accurate diagnosis and analysis. * Wide viewing angles: The IPS panel provides wide viewing angles, ensuring that medical professionals can view images clearly from different positions. * Accurate color reproduction: The monitor's color calibration technology ensures accurate and consistent color reproduction, crucial for accurate diagnosis. * Ergonomic design: The monitor is designed with ergonomic features such as height adjustment and tilt, allowing for comfortable viewing during long hours of work. * DICOM Part 14 compliance: The monitor meets the DICOM Part 14 standard, ensuring consistent and accurate grayscale reproduction, essential for medical imaging.
Q: What are the key features of the LG 21HQ513D-B?A: The LG 21HQ513D-B offers several key features that enhance its performance in medical imaging: * 21.3-inch 3MP IPS display: The monitor's high-resolution IPS panel provides detailed and accurate images. * DICOM Part 14 compliant: The monitor meets the DICOM Part 14 standard, ensuring accurate grayscale reproduction. * Auto Luminance control: The monitor automatically adjusts its brightness based on ambient lighting conditions, reducing eye strain and ensuring optimal image quality. * Color calibration: The monitor's built-in calibration software allows for precise color calibration, ensuring accurate and consistent color reproduction. * Wide viewing angles: The IPS panel provides wide viewing angles, allowing for clear image viewing from different positions. * Ergonomic design: The monitor features height adjustment, tilt, and pivot options, allowing for comfortable viewing and flexibility in positioning.
Q: In what scenarios can the LG 21HQ513D-B be beneficial?A: The LG 21HQ513D-B can be highly beneficial in various medical imaging scenarios, including: * Radiology: The high resolution and accurate color reproduction of the monitor make it ideal for radiology imaging, enabling detailed analysis and diagnosis. * Cardiology: The monitor's precise image quality and grayscale reproduction are essential for cardiology imaging, facilitating accurate interpretation of cardiac conditions. * Pathology: The monitor's sharp and detailed images aid pathologists in examining tissue samples and identifying abnormalities. * Dentistry: The monitor's high resolution and color accuracy are advantageous for dental imaging, allowing for precise analysis and treatment planning. * Veterinary medicine: The monitor's accurate image reproduction is valuable in veterinary medicine for diagnosing and treating animals.
Q: Is the LG 21HQ513D-B easy to set up and use?A: Yes, the LG 21HQ513D-B is designed for user convenience. It features a user-friendly interface and comes with easy-to-follow setup instructions. The monitor also offers customizable settings to suit individual preferences and requirements.
