Technical Specifications
| Technical Specifications | BenQ RP7503 - 75" Pro Series Interactive Display for Education |
|---|---|
| Display Size | 75 inches |
| Resolution | 4K UHD (3840 x 2160) |
| Aspect Ratio | 16:9 |
| Brightness | 400 nits |
| Touch Technology | 40-point Fine IR Plus |
| Response Time | 8 ms |
| Contrast Ratio | 1200:1 (static), 30,000:1 (dynamic) |
| Viewing Angle | 178° / 178° |
| Operating System | Android 11 |
| Memory & Storage | 8 GB RAM / 64 GB storage |
| Speakers | 2 × 16W + 1 × 16W Subwoofer, Dolby Audio |
| Microphones | 8-microphone array with noise reduction |
| Connectivity |
VGA × 1, HDMI 2.0 × 3, DP 1.2a × 1 USB-A × 7, USB-B × 3, USB-C × 2 Audio In/Out, RS232, LAN × 2 (Android / OPS) |
| Glass & Surface | 3.2 mm tempered, 9H hardness, anti-glare coating, germ-resistant |
| Power Consumption | 90W typical / 461W max / <0.5W standby |
| Dimensions (W × H × D) | 1717.1 × 1065.3 × 121.3 mm (approx. 67.6" × 41.9" × 4.8") |
| Weight | 55.5 kg (122.4 lbs) net / 70 kg (154.3 lbs) gross |
| Mounting | VESA 800 × 400 mm, M8 × 25L screws, wall mount kit included |
Description
The BenQ RP7503 is a 75-inch interactive display built for forward-thinking schools and educators. Its 4K UHD anti-glare display offers crisp visibility in any classroom setting, while the Fine IR Plus touch technology enables up to 40 students to interact at the same time. Designed to make teaching simpler and learning more immersive, this display brings digital whiteboarding, wireless sharing, and collaboration to the front of the class.
Health is a top priority with ClassroomCare® features like germ-resistant screens, styluses, and remote control. The built-in air quality sensor monitors CO₂ and dust levels, while an integrated air ionizer helps purify the space. For comfort, the screen includes TÜV-certified flicker-free and low blue light technology to reduce eye strain during extended lessons.
Onboard Android 11, 8GB RAM, and 64GB storage power smooth performance for EZWrite 6 whiteboarding, file access, or cloud tools. Teachers can run up to six apps simultaneously or connect their laptop to control content from the screen itself. The RP7503 supports flexible lesson delivery, whether you're teaching in person or remotely.
Rich audio and voice features make lessons more dynamic. Dolby-powered front-facing speakers with a subwoofer ensure students can hear every word, while the 8-microphone array filters background noise and enhances clarity. With simple device management tools and secure NFC login options, the RP7503 helps educators and IT teams focus on what matters—teaching and learning.
A: The RP7503 supports up to 40 simultaneous touch points, making it ideal for group learning, interactive games, and student collaboration.
A: The RP7503 includes sensors that detect CO₂, PM2.5, PM10, temperature, and humidity. It also features an air ionizer to help reduce airborne impurities when pollution levels rise.
A: Yes, the built-in NFC sensor allows teachers to sign in quickly using their Azure Active Directory or Google Workspace credentials.
A: Absolutely. With EZWrite 6, teachers can host interactive whiteboarding sessions across physical and remote classrooms in real time.
A: It includes dual 16W speakers and a 16W subwoofer powered by Dolby Audio, plus an 8-mic array for capturing voices clearly.
