Technical Specifications
| Model: AG Neovo QX-55 - 55" 4K Surveillance Display, 450 Nits | |
| Panel Spec | |
| Display Type | TFT-LCD |
| Size | 55" |
| Touch Screen | No |
| Resolution | 3840 x 2160 (4K) |
| Aspect Ratio | 16 : 9 |
| Color Depth | 8 bit |
| Contrast Ratio | 4000 : 1 |
| Brightness | 450 nits |
| Backlight | LED |
| Viewing Angle | 178° (H), 178° (V) |
| Interfaces | |
| HDMI | 2 x HDMI 2.0 |
| DisplayPort | 1 x DisplayPort 1.2 |
| VGA | 1 x VGA |
| Audio | 1 x Audio In, 1 x Audio Out |
| Power | |
| Power Consumption | 100W (Max) |
| Power Supply | AC 100-240V, 50/60Hz |
| Environmental | |
| Operating Temperature | 0 - 40°C |
| Storage Temperature | -20 - 60°C |
| Humidity | 10 - 90% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 25.5 kg (56.22 lbs) |
| Dimensions (L x W x H) | 1245 x 724 x 70 mm (49 x 28.5 x 2.8 in) |
| VESA Mount | 400 x 400 mm |
Description
The AG Neovo QX-55 is a 55-inch 4K surveillance display that offers exceptional clarity and detail for high-resolution security systems. With a resolution of 3840 x 2160 and 450 nits of brightness, this display ensures that you don't miss a single detail. It features versatile connectivity options, including VGA, DVI, HDMI, and DisplayPort inputs, making it easy to connect to various devices. The display is equipped with anti-burn-in technology to prevent image ghosting and NeoV Optical Glass screen to protect it from scratches and damages. With RS232/ RJ45 connection, it allows for easy control and management. The anti-glare surface treatment ensures clear visibility even in bright environments.
- Anti-Burn-in technology prevents image ghosting
- NeoV Optical Glass screen protects the display from scratches and other damages
- RS232/ RJ45 connection for easy control and management
- Anti-glare surface treatment
Experience the 4K difference with the QX-55 55-inch surveillance display. With its powerful 4K resolution and 450 nits of brightness, it delivers smooth video and graphics with exceptional detail and clarity. Whether you need it for surveillance or digital signage applications, this display offers the resolution required for demanding tasks. It also features easy control and integration capabilities with built-in RS-232 and Ethernet control. The multi-screen viewer allows you to display up to four full HD screens simultaneously, eliminating the need for multiple monitors. Designed for 24/7 operation, this display is built to last with its durable metal housing and NeoV Optical Glass screen. The PID Command & Ctrl software provides a simple and intuitive interface for remote management and control of the display.
- Multi-screen viewer for simultaneous display of up to four full HD screens
- Industry-leading reliability with 24/7 operation and durable construction
- PID Command & Ctrl software for easy remote management and control
In the Box
Frequently Asked Questions
Q: What is the AG Neovo QX-55 - 55" 4K Surveillance Display?A: The AG Neovo QX-55 is a high-quality surveillance display specifically designed for security monitoring applications. It features a 55-inch 4K display with a brightness of 450 nits, providing crisp and clear images for surveillance purposes.
Q: What are the benefits of using the AG Neovo QX-55 for surveillance?A: The AG Neovo QX-55 offers several benefits for surveillance purposes, including: * High-resolution display: The 4K resolution ensures that surveillance footage is displayed with exceptional clarity, allowing for easy identification of details. * Enhanced visibility: With a brightness of 450 nits, the display ensures that the surveillance footage remains visible even in bright environments or low-light conditions. * Wide viewing angles: The display provides wide viewing angles, ensuring that surveillance operators can easily monitor the footage from different positions without any loss in image quality. * Durability: The AG Neovo QX-55 is built to withstand the demands of continuous surveillance operations, ensuring reliable performance over time.
Q: What are the key features of the AG Neovo QX-55?A: The AG Neovo QX-55 comes with several key features that make it an ideal choice for surveillance applications, including: * 55-inch 4K display: The large screen size and high resolution provide a detailed and immersive viewing experience. * 450 nits brightness: The display's high brightness ensures clear visibility of surveillance footage in various lighting conditions. * Anti-Burn-in™ technology: This feature prevents image retention, ensuring that static surveillance images do not leave a permanent mark on the screen. * Multiple video inputs: The display offers various video input options, including HDMI, DisplayPort, and VGA, allowing for easy integration with different surveillance systems. * VESA mount compatibility: The AG Neovo QX-55 can be easily mounted on walls or stands, providing flexibility in installation.
Q: In what scenarios can the AG Neovo QX-55 be beneficial?A: The AG Neovo QX-55 is well-suited for a range of surveillance scenarios, including: * Security control rooms: The large display size and high resolution make it ideal for monitoring multiple surveillance feeds simultaneously. * Retail environments: The display can be used to monitor store entrances, aisles, or cashier areas, ensuring the safety and security of the premises. * Transportation hubs: Airports, train stations, and bus terminals can benefit from the display's clear visibility and wide viewing angles for effective surveillance. * Public spaces: The AG Neovo QX-55 can be used in parks, stadiums, or other public areas to enhance security and monitor crowd movements.
Q: How user-friendly is the AG Neovo QX-55 for surveillance operators?A: The AG Neovo QX-55 is designed with user convenience in mind. It offers intuitive controls and a user-friendly interface, allowing surveillance operators to easily navigate through settings and adjust display parameters as needed. Additionally, the display's durable construction ensures long-term reliability, reducing the need for frequent maintenance.
