Technical Specifications
| Model: LG 55XE4F-M - 55" Outdoor Display with High Brightness and Full HD | |
| Panel Spec | |
| Display Type | TFT-LCD |
| Size | 55" |
| Touch Screen | No |
| Resolution | 1920 x 1080 (Full HD) |
| Aspect Ratio | 16 : 9 |
| Color Depth | 8 bit |
| Contrast Ratio | 1,000 : 1 |
| Backlight | LED |
| Viewing Angle | 178° (H), 178° (V) |
| Interfaces | |
| Ethernet | 1 x RJ-45 Female, 10 / 100 / 1000 BaseT |
| USB | 2 x USB Type A |
| Power Inputs | |
| Power over Ethernet (PoE) | No |
| Power Consumption | AC 100-240V~, 50/60Hz |
| Environmental | |
| Operating Temperature | -30°C to 50°C |
| Storage Temperature | -30°C to 60°C |
| Humidity | 10 - 80% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 35.2 kg ( 77.6 lb ) |
| Dimensions (L x W x H) | 1247.6 x 721.4 x 109.2 mm (49.1 x 28.4 x 4.3 in.) |
| Note | N/A |
Resources
Description
The LG 55XE4F-M is a 55-inch XE4F-M series high-brightness outdoor display with a slim and lightweight design. With its upgraded brightness of 4,000 cd/m², this display can capture customers' attention even under direct sunlight. The XE4F-M series is easy to install and can handle most environments, making it a versatile choice for outdoor signage.
The slim and robust design of the XE4F-M series signage makes it easy to install and suitable for various outdoor environments. Its high brightness ensures that your customers' attention will be captured, even under strong sunlight.
The XE4F-M series features a single display with a light and slim design. It can be easily customized to suit different external environments without the need for a separate casing.
The XE4F-M series outdoor displays are ready to be customized to meet your business needs. Whether it's outdoor menu boards or kiosks, these displays are mount ready and optimized for your industry and use.
With a powerful brightness of 4,000 cd/m², the XE4F-M series provides clear and vivid picture quality even under direct sunlight.
The IPS technology used in the XE4F-M series allows the screen to be viewed at virtually any angle, providing better control of the liquid crystals.
By adding more LED units, the XE4F-M series operates brighter at a lower temperature, resulting in a longer lifespan compared to conventional products.
The XE4F-M series features QWP technology, enabling clear visibility even when the viewer is wearing polarized sunglasses.
The XE4F-M series is IP56 protected, designed to withstand water and other weather conditions. This makes it an essential feature for outdoor displays.
The tempered and laminated front glass of the XE4F-M series ensures optimum protection from outdoor extremities, minimizing damage from external impacts.
The XE4F-M series supports HDBaseT™, the global standard for the transmission of ultra-high definition video and audio, Ethernet, controls, USB, and IR over a single, long-distance cable. This allows for easier control of the display and saves installation and maintenance costs.
The web-based monitoring solution of the XE4F-M series is user-friendly and allows for full access anywhere, anytime from a mobile phone. It provides real-time monitoring, adjustments, and control of the unit, as well as access to both current and past data.
The LG 55XE4F-M is the perfect outdoor display for various applications, from outdoor advertising to digital signage. Its high brightness, slim design, and customizable features make it a versatile choice for businesses looking to capture customers' attention in outdoor environments.
In the Box
Frequently Asked Questions
Q: What is the LG 55XE4F-M - 55" Outdoor Display with High Brightness and Full HD?A: The LG 55XE4F-M is a 55-inch outdoor display designed for high brightness and full HD viewing. It is specifically built to withstand outdoor environments and offers superior visibility even in bright sunlight.
Q: What are the benefits of using the LG 55XE4F-M outdoor display?A: The LG 55XE4F-M outdoor display provides numerous benefits for various scenarios: * High Brightness: With its high brightness capabilities, the display ensures clear visibility even in direct sunlight, making it perfect for outdoor advertising and information display. * Full HD Resolution: The display offers full HD resolution, delivering crisp and detailed visuals for an enhanced viewing experience. * Weatherproof Design: The LG 55XE4F-M is designed to withstand harsh weather conditions, ensuring durability and reliability in outdoor environments. * Wide Viewing Angle: The display provides a wide viewing angle, allowing people from different positions to view the content without any distortion. * Energy Efficiency: The display is energy-efficient, reducing power consumption and contributing to cost savings.
Q: What are the key features of the LG 55XE4F-M outdoor display?A: The LG 55XE4F-M outdoor display comes with several key features that make it a great choice for outdoor applications: * High Brightness: The display offers a high brightness level of X nits, ensuring excellent visibility even in bright sunlight. * Full HD Resolution: It features a full HD resolution of 1920 x 1080 pixels, delivering sharp and detailed images. * Weatherproof Design: The display is IP-rated and designed to withstand various weather conditions, including rain, dust, and extreme temperatures. * Anti-Reflective Coating: The display includes an anti-reflective coating, minimizing glare and reflections for improved visibility. * Portrait and Landscape Orientation: The LG 55XE4F-M can be installed in both portrait and landscape orientations, providing flexibility for different content formats. * Remote Monitoring and Control: The display supports remote monitoring and control, allowing easy management and content updates.
Q: What are some of the applications for the LG 55XE4F-M outdoor display?A: The LG 55XE4F-M outdoor display can be utilized in various scenarios, including: * Outdoor Advertising: The high brightness and weatherproof design make it ideal for displaying advertisements and promotional content in outdoor locations. * Wayfinding and Information Display: The display can be used to provide directions, information, and updates in public spaces, parks, and transportation hubs. * Outdoor Events and Exhibitions: It can be utilized for showcasing content, schedules, and interactive experiences during outdoor events and exhibitions. * Hospitality and Entertainment: The display can enhance the outdoor entertainment experience in hotels, resorts, and amusement parks by displaying engaging content.
Q: How easy is it to install and maintain the LG 55XE4F-M outdoor display?A: The LG 55XE4F-M outdoor display is designed for easy installation and maintenance. It can be mounted on various outdoor structures using compatible mounting brackets. Additionally, the display includes features like remote monitoring and control, enabling convenient management and content updates without the need for physical access.
